29
4-1-1. Preset Event Stored in FA-9600
1. Event No: 91/95
Event name: F1/F2_S2H_Disp
Conversion: Display-referred conversion from SDR to HLG
(Example in ITU-R BT.2390)
Application: Converts SDR contents to HDR (HLG) for HDR broadcasting.
2. Event No: 92/96
Event name: F1/F2_H2S_Disp
Conversion: Display-referred conversion from HLG to SDR referring to Display.
Inverse conversion of No 1.
Application: Converts contents created in HLG or Live HLG programs to SDR.
Monitors an HLG camera on SDR monitors
3. Event No: 93/97
Event name: F1/F2_S2H_Scen
Conversion: Scene Referred conversion from SDR to HLG
Application: Converts SDR camera images to HLG for HDR broadcasting.
4. Event No: 94/98
Event name: F1/F2_H2S_Scen
Conversion: Scene Referred conversion from HLG to SDR. Inverse conversion of No. 3
Application: Converts HLG camera images to SDR for SDR broadcasting.
5. Event No: 81/83
Event name: F1/F2_H2S_Disp_wKN
Conversion: Display Referred conversion from HLG to SDR with Knee function
Application: Converts HLG product or live contents to SDR contents.
Monitoring HLG cameras on SDR monitors.
6. Event No: 82/84
Event name: F1/F2_H2S_Scen_wKN
Conversion: Scene Referred conversion from HLG to SDR with Knee function
Application: Converts HLG camera images to SDR for SDR broadcasting.
7. Event No: 99/100
Event name: F1/F2_Bypass(CC)
Conversion: Disables Dynamic Range and Color Gamut conversions, Gain adjustment
and Knee function.
Application: Passes through inputs without changing Dynamic Range and Color gamut.
Disables Dynamic Range and Color Gamut conversions, Gain adjustment
and Knee function after loading other events.
Parameter settings in preset events
Event No
Referred
Conversion
Input Gamma
Curve
/ Color Space
Output Gamma
Curve
/ Color Space
OOTF
(Input)
Inverse
OOTF
(Output)
SDR GAIN
(dB)
Knee
FS1
FS2
1
91
95
Display
SDR to HLG
SDR 2.4 BT.1886
/ BT.709
HLG BT.2100
/ BT.2020
Disable
Inverse
OOTF
6.15
Disable
2
92
96
HLG to SDR
HLG BT.2100
/ BT.2020
SDR 2.4 BT.1886
/ BT.709
Enable
Disable
6.15
Disable
3
93
97
Scene
SDR to HLG
SDR 2.2 BT.709
/ BT.709
HLG BT.2100
/ BT.2020
Disable
Disable
10.04
Disable
4
94
98
HLG to SDR
HLG BT.2100
/ BT.2020
SDR 2.2 BT.709
/ BT.709
Disable
Disable
10.04
Disable
5
81
83
Display
HLG to SDR
HLG BT.2100
/ BT.2020
SDR 2.4 BT.1886
/ BT.709
Enable
Disable
6.15
Enable
6
82
84
Scene
HLG to SDR
HLG BT.2100
/ BT.2020
SDR 2.2 BT.709
/ BT.709
Disable
Disable
10.04
Enable
