111
MADI OUTPUT GAIN
Master Mute setting
6-21
AUDIO MUTE/TEST SIGNAL
All settings
7-3
8-1. Items Not Stored in Event Memory
The following menu items are not stored in event memory.
Menu
Item not stored
Sec.
VIDEO PROCESS AMPLIFIER
Keep White setting
5-1
SPLIT MODE SELECT
Mode setting
5-2
AREA MARKER
Marker
5-3
INPUT LINKAGE PROCESS (VIDEO)
All menu settings
5-16
INPUT LINKAGE PROCESS (AUDIO)
All menu settings
5-17
VIDEO PAYLOAD ID LINKAGE
All menu settings
5-31
VIDEO FREEZE
Freeze
5-41
FRAME DELAY
Mode
5-42
VIDEO INPUT STATUS
|
INPUT TIMECODE DETECTION
All information and status
5-45
|
5-51
AUDIO OUTPUT GAIN
Master Mute setting
6-19
ANALOG INPUT/OUTPUT GAIN
Master Mute setting
6-20
MADI OUTPUT GAIN
Master Mute setting
6-21
GPI UTILITY / INPUT / OUTPUT
All menu settings
7-1
FRONT PANEL SETTINGS
All menu settings
7-5
NETWORK INFORMATION
NETWORK SETTING
Network settings
7-6
7-7
MU OPERATION
MU Main mode setting
7-8
EMB. AUDIO INPUT STATUS
|
SOFTWARE OPTION INFO.
All information and status
7-9
|
7-21
START UP EVENT
All menu settings
8
Main Unit tab
Unit / FS Name settings
11
Network tab
All menu settings
11-6
◆ Notes on Event Memory
 Do not power off the FA-9600 unit while saving data to event memory. Otherwise, event data is
not stored correctly.
 Wait at least 5 seconds and power off the FA-9600 unit before changing settings, since the unit
regularly auto-saves setting data. (See Sec. 3-2. “Memory Access Icon”.)
 It is recommended to back up important data as files, referring to Sec. 13-3-2. “Event Data.”
