15. SNMP Monitoring
The FA-9600 can be remotely monitored using the SNMP v2c protocol. MIB (Management Information
Base) required for the monitoring is included in the supplied CD-ROM. See Sec. 13-2-2 "SNMP System
Settings" for details about the SNMP network settings.
◆ SET/GET List
Object group
Item name
Object name in MIB file
Value
OID
Type
Trap
Note
OID : 1.3.6.1.4.1.20175.1.338.1.1. ( Unit Info )
Unit info.
Product Name
fa9600ProductName
1
OCTET STRING
Product Code
fa9600ProductCode
2
INTEGER
Unit Name
fa9600UnitName
3
OCTET STRING
Serial Number
fa9600SerialNumber
4
INTEGER
Firmware1 Ver
fa9600Firmware1Version
10
OCTET STRING
Firmware2 Ver
fa9600Firmware2Version
11
OCTET STRING
FPGA1 Ver.
fa9600Fpga1Version
12
OCTET STRING
FPGA2 Ver.
fa9600Fpga2Version
13
OCTET STRING
FPGA3 Ver.
fa9600Fpga3Version
14
OCTET STRING
FA-964K Inst.
fa964KInstalled
0: notInstalled
1: installed
21
INTEGER
FA-96UDC Inst.
fa96UdcInstalled
0: notInstalled
1: installed
22
INTEGER
AHDR Option Inst.
fa96AhdrOption
0: notInstalled
1: fa96Ahdr
2: fa96Ahdr2
24
INTEGER
OID : 1.3.6.1.4.1.20175.1.338.1.1.31 (Option Slot Info )
Option info.
SlotA Name
fa9600SlotAOptionName
1
OCTET STRING
SlotA Firm.Ver.
fa9600SlotAOptionFirmwareVersion
2
OCTET STRING
SlotA FPGA1 Ver.
fa9600SlotAOptionFpga1Version
3
OCTET STRING
SlotA FPGA2 Ver.
fa9600SlotAOptionFpga2Version
4
OCTET STRING
SlotB Name
fa9600SlotBOptionName
11
OCTET STRING
SlotB Firm.Ver.
fa9600SlotBOptionFirmwareVersion
12
OCTET STRING
SlotB FPGA1 Ver.
fa9600SlotBOptionFpga1Version
13
OCTET STRING
SlotB FPGA2 Ver.
fa9600SlotBOptionFpga2Version
14
OCTET STRING
SlotC Name
fa9600SlotCOptionName
21
OCTET STRING
SlotC Firm.Ver.
fa9600SlotCOptionFirmwareVersion
22
OCTET STRING
SlotC FPGA1 Ver.
fa9600SlotCOptionFpga1Version
23
OCTET STRING
SlotC FPGA2 Ver.
fa9600SlotCOptionFpga2Version
24
OCTET STRING
FA-96DIN4 Inst.
fa96Din4OptionInstalled
0: notInstalled
1: installed
41
INTEGER
FA-96DB9 Inst.
fa96Db9OptionInstalled
0: notInstalled
1: installed
51
INTEGER
OID : 1.3.6.1.4.1.20175.1.338.1.2. ( Status )
OID : 1.3.6.1.4.1.20175.1.338.1.2.1 ( Unit Status )
Unit Status
Fan1 Status
fa9600Fan1Status
0: normal
1: stopped
1
INTEGER
✔
Fan2 Status
fa9600Fan2Status
0: normal
1: stopped
2
INTEGER
✔
Fan3 Status
fa9600Fan3Status
0: normal
1: stopped
3
INTEGER
✔
PowerStatus1
fa9600PowerSupplyUnitStatus1
-1: notInstalled
0: normal
1: abnormal
11
INTEGER
✔
PowerStatus2
fa9600PowerSupplyUnitStatus2
-1: notInstalled
0: normal
1: abnormal
12
INTEGER
✔
FPGA1 Temp.
fa9600Fpga1Temperature
21
INTEGER
FPGA2 Temp.
fa9600Fpga2Temperature
22
INTEGER
✔
OID : 1.3.6.1.4.1.20175.1.338.1.2.2 ( Video Status )
Genlock Status
Genlock Status
fa9600GenlockInputStatus
11
OCTET STRING
✔
OID : 1.3.6.1.4.1.20175.1.338.1.2.2.1 ( Input Video Status )
Input Status
Input SDI1 Status
fa9600InputVideoStatusSdi1
1
OCTET STRING
✔
Input SDI2 Status
fa9600InputVideoStatusSdi2
2
OCTET STRING
✔
Input HDMI Status
fa9600InputVideoStatusHdmi
3
OCTET STRING
✔
OID : 1.3.6.1.4.1.20175.1.338.1.2.2.2 ( Output Video Status )
Output Status
Output SDI1 Status
fa9600OutputVideoStatusSdi1A
1
OCTET STRING
fa9600OutputVideoStatusSdi1B
2
OCTET STRING
Output SDI2 Status
fa9600OutputVideoStatusSdi2A
3
OCTET STRING
fa9600OutputVideoStatusSdi2B
4
OCTET STRING
Output HDMI Status
fa9600OutputVideoStatusHdmi
5
OCTET STRING
