FOR-A FA-9600 Series User Manual

186
Object group
Item name
Object name in MIB file
Value
OID
Type
Trap
Note
OID : 1.3.6.1.4.1.20175.1.338.1.2.2.2 ( Output Video Status )
Output
Status
Output SDI1 Status
fa9600OutputVideoStatusSdi1A
1
OCTET STRING
fa9600OutputVideoStatusSdi1B
2
OCTET STRING
Output SDI2 Status
fa9600OutputVideoStatusSdi2A
3
OCTET STRING
fa9600OutputVideoStatusSdi2B
4
OCTET STRING
Output HDMI
Status
fa9600OutputVideoStatusHdmi
5
OCTET STRING
OID : 1.3.6.1.4.1.20175.1.338.1.2.3 ( Audio Status )
OID : 1.3.6.1.4.1.20175.1.338.1.2.3.1.1 ( Audio Emb1 Status )
Audio Emb1
Status
Channel
fa9600EmbeddedAudioStatusCha
nnel1
1-16
1.a
INTEGER
*1*2
Audio Status
fa9600EmbeddedAudioInputChan
nelStatus1
0: loss
1: pcm
2: asyncPcm
3: silence
4: asyncsilence
5: dolby-e
6: asyncDolby-E
7: nonPcm
8: asyncNonPcm
9: by-pass
11.a
INTEGER
✔
*1
OID : 1.3.6.1.4.1.20175.1.338.1.2.3.2.1 ( Audio Emb2 Status )
Audio Emb2
Status
Channel
fa9600EmbeddedAudioStatusCha
nnel2
(Same as Emb1)
1.a
INTEGER
*1*2
Audio Status
fa9600EmbeddedAudioInputChan
nelStatus2
(Same as Emb1)
11.a
INTEGER
✔
*1
OID : 1.3.6.1.4.1.20175.1.338.1.2.3.3.1 ( Audio AES Status )
Audio AES
Status
Channel
fa9600AesAudioStatusChannel
1-8
1.a
INTEGER
*1*2
Audio Status
fa9600AesAudioInputChannelStat
us
0: loss
1: pcm33K
2: pcm44K1
3: pcm48K
4: silence33K
5: silence44K1
6: silence48K
7: dolby-e
8: nonPcm
9: outputSetting
11.a
INTEGER
✔
*1
OID : 1.3.6.1.4.1.20175.1.338.1.2.4 ( Slot Option Status )
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.1 ( SlotA Option Status )
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.1.1 ( FA-96EX3G44-R Status )
FA-96EX3G4
4-R Status
Input SDI Status1
fa96Ex3G44RInputSdiStatus1
1
OCTET STRING
✔
Input SDI Status2
fa96Ex3G44RInputSdiStatus2
2
OCTET STRING
✔
Input SDI Status3
fa96Ex3G44RInputSdiStatus3
3
OCTET STRING
✔
Input SDI Status4
fa96Ex3G44RInputSdiStatus4
4
OCTET STRING
✔
Output SDI Status1
fa96Ex3G44ROutputSdiStatus1
11
OCTET STRING
Output SDI Status2
fa96Ex3G44ROutputSdiStatus2
12
OCTET STRING
Output SDI Status3
fa96Ex3G44ROutputSdiStatus3
13
OCTET STRING
Output SDI Status4
fa96Ex3G44ROutputSdiStatus4
14
OCTET STRING
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.1.2 ( FA-96EX12G06 Status )
FA-96EX12G
06-R Status
Output SDI Status1
fa96Ex12G06ROutputSdiStatus1
1
OCTET STRING
Output SDI Status2
fa96Ex12G06ROutputSdiStatus2
2
OCTET STRING
Output SDI Status3
fa96Ex12G06ROutputSdiStatus3
2
OCTET STRING
Output SDI Status4
fa96Ex12G06ROutputSdiStatus4
3
OCTET STRING
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.1.3 ( FA-96SFPC4 Status )
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.1.3.1.1 ( FA-96SFPC4 Rx Status )
FA-96SFPC4
Rx Status
Channel
fa96Sfpc4RxStatusChannel
1 - 4
1.a
INTEGER
*1*2
SFP Rx Signal
Status
fa96Sfpc4RxVideoStatus
2.a
OCTET STRING
✔
*1
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.1.3.2.1 ( FA-96SFPC4 Tx Status )
FA-96SFPC4
Tx Status
Channel
fa96Sfpc4TxStatusChannel
1 - 4
1.a
INTEGER
*1*2
SFP Tx Status
fa96Sfpc4TxVideoStatus
2.a
OCTET STRING
*1
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.2 ( SlotB Option Status )
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.2.1.1.1 ( FA-96AES-UBL Status )
FA-96AES-
UBL Status
Channel
fa96AesUblStatusChannel
(Same as Audio
AES)
1.a
INTEGER
*1*2
Audio Status
fa96AesUblInputChannelStatus
(Same as Audio
AES)
11.a
INTEGER
✔
*1
OID : 1.3.6.1.4.1.20175.1.338.1.2.4.2.2.1.1 ( FA-96ANA-AUD Status(Slot B) )
FA-96ANA-
AUD Status
Channel
fa96AnaAudStatusBChannel
1 - 4
1.a
INTEGER
*1*2
Audio Status
fa96AnaAudStatusBChannelStatus
0: silence
1: present
11.a
INTEGER
✔
*1
