FOR-A FA-9600 Series - 11-2-3. Converter 1-2

118
<Simultaneous 4K/HD mode>
<3D-LUT mode>
Item
Default
Setting
Description
Source
Select
SDI 1 (FS1)
SDI 2 (FS2)
IN1
IN2
HDMI IN
EX3G IN1 to IN4
SFP RX1 to RX4
Selects a signal input to FS1 or FS2.
EX3G IN1 to EX3G IN4: Require
FA-96EX3G44-R.
SFP RX1 to SFP RX4: Require FA-96SFPC4.
Input Link
(UHD)
(FA-964K)
Single Link
Single Link
Dual Link
Quad Link
Selects an SDI Link format for UHD 4K.(Quad
Link requires FA-96EX3G44-R or
FA-96SFPC4)
Terminal
Assign
-
-
Displays the signal status that is selected
under Source Select (FS1 only).
Loss Mode
W/o
FA-964K
(FS1/2)
Black
Color
Back Color
Auto Freeze
SDI Output Mute
Selects the output mode for input signal loss.
Back Color: Outputs a monochrome (set
under Back Color below) video.
Auto Freeze: Freezes and outputs the last
normal video.
SDI Output Mute: Outputs no video signal so
that the FA-9600 downstream device can
detect video loss.
W/
FA-964K
(FS1)
Black
Color
(Link)
Back Color (Link)
Back Color
(Separate)
Auto Freeze
SDI Output Mute
(Link)
SDI Output Mute
(Separate)
See <p 46> for 4K multi-link input loss.
Back Color (Link): Outputs a monochrome
(set under Back Color below) video.
Back Color (Separate): Output the input
video displaying monochrome (set under Back
Color) for the lost part.
SDI Output Mute(Link): Stops video output if
any one of four links is lost for Quad Link video.
SDI Output Mute(Separate): Stops video
output if all four links are lost for Quad Link
video.
Back Color
Black
Black, Blue
Red, Magenta
Green, Cyan
Yellow
Specifies a color used in Loss Mode.
Format
Setting
Auto Detect
Auto Detect
Manual
Specifies the FS output format.
Auto: FS input signal format.
Manual: Signal format specified below.
If Format Setting is set to Manual, specify the format using the following settings.
For supported video formats, see Sec. 16-1. “Specifications.”
Standard
1080
SD
720
1080
2160
Specifies the vertical image resolution.(2160
available only on FS1 and FA-964K required)
Horizontal
Size
1920/3840
1920/3840
(Not used)
Frame Rate
59.94i
60p, 59.94p, 50p
48p, 47.95p
30p, 29.97p
25p, 24p, 23.98p
60i, 59.94i, 50i
24PsF, 23.98PsF
30PsF, 29.97PsF
25PsF
Specifies the frame / field rate.
Level
Follow Input
Follow Input
Level-A
Level-B
Specifies the SDI mapping level.
