CFM Mode
Display of Turbulence (T)
The Turbulence is coded in a single color wedge:
Less turbulent: dark green more turbulent: light green
(low brightness) (high brightness)
Display of Velocity and Turbulence (V-T)
This is the Mode for high flow with turbulence (display of variance).
low flow < ---- > high flow
CFM Map 1 Forward flow: dark red – light red
- Turbulence: dark orange – orange
Reverse flow: dark blue – light blue
- Turbulence: dark green – green
CFM Map 2 Forward flow: red – orange
- Turbulence: dark yellow – yellow
Reverse flow: blue – cyan
- Turbulence: green – light green
CFM Map 3 Forward flow: dark red – light red – yellow
- Turbulence: dark red – green
Reverse flow: dark blue – light blue – cyan
- Turbulence: dark blue – light green
CFM Map 4 Forward flow: red – light red
- Turbulence: yellow – light green
Reverse flow: blue – cyan
- Turbulence: green – light green
CFM Map 5 Forward flow: dark red – yellow
- Turbulence: dark green – green
Reverse flow: dark blue – cyan
- Turbulence: dark green – light green
CFM Map 6 Forward flow: red – yellow
- Turbulence: green – light green
Reverse flow: blue – cyan
- Turbulence: dark green – light green
CFM Map 7 Forward flow: dark red – light red
- Turbulence: green – light green
Reverse flow: violet – light violet
- Turbulence: green – light green
Low flow is displayed by dark red or dark blue (depending on the direction).
With increasing velocity the color changes from dark red to yellow (depending on the selected CFM
Map curve) review: CFM Map
(chapter 8.3.9).
Voluson® 730Pro - Basic User Manual
8-10 105831 Rev. 0
