TD Mode
10.3.8 Balance
“Balance” controls the amount of Color displayed over bright echoes and helps confine Color within
the vessel walls. Decreasing this Balance displays Color on brighter structures.
If you see no color, the Balance is probably set too high.
Rotate the [Balance] digipot and select the useful Balance.
The Balance orientation line is only visible in the color modes.
The line represents to the position of the adjusted displayed gray
value in the gray scale.
Remarks:
* Changes are only possible in write mMode !
10.3.9 Dynamic Set
“Dynamic Set” controls the axial resolution of color in the display.
It adjusts the axial sample depth of color pixels.
When rotating counter-clockwise the color information is sharper (edges more pixely).
When rotation clockwise the color information is less sharp (edges smoothed).
Rotate the [Dyn.Set] digipot and select the desired dynamic range. Set 1 to Set 8.
1-4 color samples in axial direction shorter
4-8 color samples in axial direction larger
Remarks:
*
Changes are only possible in write mode.
Voluson
®
730Pro - Basic User Manual
105831 Rev. 0 10-11
