Volume Mode
11.2 Volume Acquisition: 3D Sectional Planes
1. Activate the Volume mode (hard key).
2. Select [Sect. Planes] Visualization mode from the menu area.
3. Select a 3D User Program (e.g., Default).
The preset values are loaded.
4. Select the display format desired.
Note:
The selected format will be present in read mode after the acquisition is done.
5. Place the Volume box over the region of interest.
The trackball has two functions: position and size of the Volume box
The activated function is displayed in status area on the monitor.
Press the upper trackball key to change the function of the trackball from position
to size or vice versa.
6. Change the size of the Volume box by moving the trackball.
Moving: ↑ decrease the box size in vertical direction
↓ increase the box size in vertical direction
→ increase the box size in horizontal direction
← decrease the box size in horizontal direction
7. Set the volume sweep angle using the toggle switch shown in the status area.
Voluson
®
730Pro - Basic User Manual
11-12 105831 Rev. 0
