Description of the System
3.3 System Assembly
3.3.1 Basic System
It consists of the following modules:
1. Probe connector module:
This module houses the entire electronics for all connections, up to 3 probe
connectors and the beamformer module (transmit and receive electronics).
Control console:
The control console consists of the hard keys, digipots, navigation wheel and the trackball,
the loudspeakers, and the probe holders.
2. Color monitor
3. Trolley:
All modules mentioned above are arranged within the trolley. There are 4 wheels. The front wheels are
equipped with locking brakes. Underneath the control console is space for auxiliary equipment (e.g.,
SCSI-drives).
4. Doppler module:
Spectral Doppler module enables the evaluation of blood flow ratios with pulsed wave and is built into
the main electronic module.
Color Doppler module enables color-coded evaluation of blood flow conditions and is built into the
main electronic module.
3.3.2 Optional Peripheral Devices
Video printer (black/white)
SCSI printer (color)
Line printer
Video tape recorder (S-VHS)
MO Drive
Footswitch
ECG preamplifier (MAN)
Actual type: review product catalog of VOLUSON® 730Pro
WARNING !
The leakage current of the entire system including any/all auxiliary equipment must
not exceed the limit values as per EN60.601-1:1990 (IEC 60601-1) resp. other valid
national or international standards.
Remark:
Optional devices (Printer, VTR, etc.) according to the pricelist of the VOLUSON
730Pro unit fulfill the electrical safety requirements.
Connection of auxiliary equipment: To Connect Internal and External Accessories
(chapter 21.2).
Voluson® 730Pro - Basic User Manual
3-6 105831 Rev. 0
