APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 329
GLOBAL FUNCTIONS
Global
Intensity
Selects intensity level for the composite image 0-255 0-100 255 100
Global Effects
Global
Ef
fect Mode
1, 2, 3, 4 & 5
Off, no effects selection 0 0
0 0
CMY simulates CMY by subtracting RGB. Reduces
col
or values. Mod1 = cyan, Mod2 = magenta,
Mod3 = yellow
1
NA
CMY adds to all pixels. Increases color values.
Mod1 = cyan, Mod2 = magenta, Mod3 = yellow
2
CMY adds to non-black pixels. Increases color values.
Mod1 = cyan, Mod2 = magenta, Mod3 = yellow
3
RGB Add, all pixels. Mod1 = red, Mod2 = green,
Mod3 = blue
4
RGB Add 2, all pixels. Mod1 = red, Mod2 = green,
Mod3 = blue
5
RGB Add, non-black pixels. Mod1 = red, Mod2 = green,
Mod3 = blue
6
RGB Swap to GBR. Mod1 = red, Mod2 = green,
Mod3 = blue.
7
RGB Swap to BRG. Mod1 = red, Mod2 = green,
Mod3 = blue.
8
Solarize 1 If color value < DMX value, invert color.
Mod1 = red, Mod2 = green, Mod3 = blue.
9
Solarize 2 If color value > DMX, invert color.
Mod1 = red, Mod2 = green, Mod3 = blue.
10
Solarize 3 If color value < DMX, set color to 0.
Mod1 = red, Mod2 = green, Mod3 = blue.
11
Solarize 4 If color value > DMX, set color to 0.
Mod1 = red, Mod2 = green, Mod3 = blue.
12
DotP and Resample. Mod1, Mod2 and Mod3 control
resamp
ling.
13
Color Cycle, DMX value controls cycle speed.
Mod1 = red, Mod2 = green, Mod3 = blue.
14
All or nothing. Mod1 = red, Mod2 = green, Mod3 = blue. 15
Solid color RGB, Mod1 = red, Mod2 = green,
Mod3 = blue.
16
RGB Invert Mod1 = red to cyan, Mod2 = green to
mage
nta, Mod3 = blue to yellow
17
RGB Invert & Swap to GBR. Mod1 = red to magenta,
Mod2 = green to yellow, Mod3 = blue to cyan
18
Parameter Description
DMX Value Default
Dec. % Dec. %
