High End Systems DL.3 - Page 356

APPENDIX A
DMX Protocol
330 DL.3 Digital Light User Manual
Global
Effect Mode
1, 2, 3, 4 & 5
RGB Invert & Swap to BRG. Mod1 = red to yellow,
Mod2 = green to cyan, Mod3 = blue to magenta
19
NA 0 0
Edge Detect Color. Mod1 = horizontal size,
Mod2 = vertical search size, Mod3 = comparison
thres
hold
20
Edge Detect B/W. Mod1 = horizontal size,
Mod2 = vertical search size, Mod3 = comparison
thres
hold
21
Texture Ripple, Horizontal. Mod1 = size, Mod2 = rate,
Mod3 = offset
22
Texture Ripple, Vertical. Mod1 = size, Mod2 = rate,
Mod3 = offset
23
Texture Ripple, Circular. Mod1 = size, Mod2 = rate,
Mod3 = offset
24
Texture Ripple, Asymmetrical Circular. Mod1 = size,
Mod2 = rate, Mod3 = offset
25
Transparent Color Fine. Select key color. Mod1 = red,
Mod2 = green, Mod3 = blue
26
Transparent Color Medium. Select key color.
Mod1 = red, Mod2 = green, Mod3 = blue
27
Transparent Color Coarse. Select key color.
Mod1 = red, Mod2
= green, Mod3 = blue
28
Transparent Color Invert, Fine. Select key color
Mod1 = red, Mod2 = green, Mod3 = blue
29
Transparent Color Invert, Medium. Select key color
Mod1 = red, Mod2 = green, Mod3 = blue
30
Transparent Color Invert, Coarse. Select key color
Mod1 = red, Mod2 = green, Mod3 = blue
31
Scan Line. Mod1 selects scan line as texture, Mod2
fad
es from original image to converted image, Mod3 not
used, reserved
32
Transparent wipes. Mod1 = width and transparent area,
Mod2 = center of transparent area,
Mod3 = transparency mode
33
Pixel Twist. Mod1 = x twist center, Mod2 = y twist
cent
er, Mod3 = direction and amount of twist
34
Picture-in-Picture. Mod1 = x subpicture center,
Mod2 = y subpicture center, Mod3 = subpicture size
35
Magnifying lens, Mod1 = x lens center, Mod2 = y lens
cent
er, Mod3 lens size
36
Magnifying lens 2, Mod1 = x lens center, Mod2 = y lens
cent
er, Mod3 = lens size
37
Parameter Description
DMX Value Default
Dec. % Dec. %
