APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 335
Global
Effect Mode
1, 2, 3, 4 & 5
Segmented Collage Gen 3, improves edge blending.
Otherwise, the same as global effect 146. Mod1 = grid
style
selection, Mod2 = grid portion displayed,
Mod3 = edge blend
152
NA 0 0
Segmented Collage Gen 3 Wrap, improves edge
bl
ending. Otherwise, the same as global effect 147.
Mod1 = grid style selection, Mod2 = grid portion
di
splayed, Mod3 = edge blend.
153
Reserved. Defaults to effect 0 152-252
Special value used with global spherical mapping effect
142
. Defaults to 0 otherwise.
253
Special value used with global spherical mapping effect
142
. Defaults to 0 otherwise.
254
Pan and Scan. Mod1 = horizontal position,
Mod2 = vertical position, Mod3 = Zoom
255
Global Effect
Modi
fier 1
These Modifier parameters adjust the option selected in
th
e corresponding channel of each of the five Global
Effects Modes.The type of adjustment and the default
value depends on the particular effect option.
NOTE: Setting the Graphic Effect Mode DMX = 253 or
254
activates specific spherical mapping control options
for Modifier parameters. For more about Modifier
parameter functionality, see
Global Effect Mode
Channels
on page 116, and specific effect options listed
alphabetically in Chapter 13.
0-255 0-100
NA NA
Global Effect
Modi
fier 2
0-255 0-100
Global Effect
Modi
fier 3
0-255
0-100
Parameter Description
DMX Value Default
Dec. % Dec. %
