APPENDIX A
DMX Protocol
334 DL.3 Digital Light User Manual
Global
Effect Mode
1, 2, 3, 4 & 5
Curve Correction, Vertical Concave Cylinder.
Mod1 = correction, Mod2 = adjusts vertical centerpoint,
Mod3 = Not used
136
NA 0 0
Curve Correction, Vertical Inside Corner.
Mod1 = correction, Mod2 = adjusts vertical centerpoint,
Mod3 = adjusts horizontal centerpoint
137
Curve Correction, Vertical Outside Corner.
Mod1 = correction, Mod2 = adjusts vertical centerpoint,
Mod3 = adjusts horizontal centerpoint
138
Curved Surface, Outside Sphere. Mod1 = correction,
Mod2 = adjusts vertical centerpoint, Mod3 = adjusts
horiz
ontal centerpoint
139
Curved Surface, Inside Sphere. Mod1 = correction,
Mod2 = adjusts vertical centerpoint, Mod3 = adjusts
horiz
ontal centerpoint.
140
Enhanced Collage Generator. Mod1 = grid style selec-
ti
on, Mod2 = grid portion displayed, Mod3 = edge blend.
141
Spherical Mapping. Outside. Mod1 = longitude angle,
Mod2 = latitude angle, Mod3 = center latitude.
142
Spherical Mapping. Inside. Mod1 = longitude angle,
Mod2 = latitude angle, Mod3 = center latitude.
143
Mattes. Mod1 = Mode, Mod2 = Matte Select,
Mod3 = texture source
144
Enhanced Collage Wrap. Mod1 = array type,
Mod2
= display cell, Mod3 = edge blending
145
Segmented Collage Generator. Mod1 = array type,
Mod2 = display cell, Mod3 = edge blending
146
Segmented Collage Generator Wrap. Mod1 = array
typ
e, Mod2 = display cell, Mod3 = edge blending
147
Output Correction, Horizontal Convex Cylinder.
Mod1 = correction, Mod2 = adjusts horizontal
cent
erpoint, Mod3 = Not used
148
Output Correction, Horizontal Concave Cylinder.
Mod1 = correction, Mod2 = adjusts horizontal
cent
erpoint, Mod3 = Not used
149
Collage Gen 3, improves blending. Otherwise, the same
as glo
bal effect 141. Mod1 = grid style selection,
Mod2 = grid portion displayed, Mod3 = edge blend
150
Collage Gen 3 Wrap, improved blending. Otherwise, the
same as gl
obal effect 145. Mod1 = grid style selection,
Mod2 = grid portion displayed, Mod3 = edge blend
151
Parameter Description
DMX Value Default
Dec. % Dec. %
