APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 337
Mask Select
Strobing Masks
0 0
Periodic strobe, round “iris” mask closing outside in. 128 50
Round iri
s closing from inside out 129
NA
Rectangle closing from outside in 130
Rectangle closing from inside out 131
Checkerboard, variation 1 132
Checkerboard, variation 2 133
Radial wipe, variation 1 134
Radial wipe, variation 2 135
Radial wipe, variation 3 136
Radial wipe, variation 4 137
Triangles, variation 1 138
Triangles, variation 2 139
Rectangular wrap 140
Tiles closing in 141
Horizontal doors, closing 142
Horizontal doors closing from opposing sides 143
Vertical doors closing from outside in 144
Vertical wipe closing from inside out 145
Rectangular tiles closing from inside out 1 146
Rectangular tiles closing from inside out 2 147
Vertical panels closing from outside in 1 148
Vertical panels closing from outside in 2 149
Vertical diamonds 1 150
Vertical diamonds 2 151
Horizontal diamonds 1 152
Horizontal diamonds 2 153
Pinwheel 154
Oval Iris closing from outside in 155
Oval Iris closing from inside out 156
Oscillating iris closing from outside in 157
Animated Dynamic Iris 158
Reserved for other strobing installed masks 159-255
Mask Size Adjusts mask size from fully closed to open 0-255 0-100 255 100
Mask Edge
Fad
e
Hard edge to faded edge when Mask Select = 0-127.
S
trobe rate control from fastest to slowest when Mask
Select parameter value = 128-255
0-255 0-100 0
0
Parameter Description
DMX Value Default
Dec. % Dec. %
