APPENDIX A
DMX Protocol
338 DL.3 Digital Light User Manual
Global Image Edge Fade
Image Edge
Fad
e, Top
Adjusts the image’s top edge diffusion from hard edge
(0
) to maximum fade (255)
0-255 0-100 0 0
Image Edge
Fad
e, Right
Adjusts the image’s right edge diffusion from hard edge
(0
) to maximum fade (255)
0-255 0-100 0 0
Image Edge
F
ade, Bottom
Adjusts the image’s bottom edge diffusion from hard
edge (0) to maxi
mum fade (255)
0-255 0-100 0 0
Image Edge
F
ade, Left
Adjusts the image’s left edge diffusion from hard edge
(0
) to maximum fade (255)
0-255 0-100 0
0
Global Keystone Correction
Keystone X
T
op Left
Moves top left corner x value to center 0-255 0-100 0 0
Keystone Y
T
op Left
Moves top left corner y value to center 0-255 0-100 0 0
Keystone X
T
op Right
Moves top right corner x value to center 0-255 0-100 0 0
Keystone Y
T
op Right
Moves top right corner y value to center 0-255 0-100 0 0
Keystone X
B
ottom Right
Moves bottom right corner x value to center 0-255 0-100 0 0
Keystone Y
B
ottom Right
Moves bottom right corner y value to center 0-255 0-100 0 0
Keystone X
B
ottom Left
Moves bottom left corner x value to center 0-255 0-100 0 0
Keystone Y
B
ottom Left
Moves bottom left corner y value to center 0-255 0-100 0 0
Keystone X
Ra
tio
Compresses and expands image horizontally 0-255 0-100 128 50
Keystone Y
Ra
tio
Compresses or expands image vertically 0-255 0-100 128
50
Global Framing
Framing X
T
op Left
Clip image from top left corner x value 0-255 0-100 0 0
Framing Y
T
op Left
Clip image from top left corner y value 0-255 0-100 0 0
Framing X
T
op Right
Clip image from top right corner x value 0-255 0-100 0 0
Framing Y
T
op Right
Clip image from top right corner y value 0-255 0-100 0
0
Parameter Description
DMX Value Default
Dec. % Dec. %
