APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 339
Framing X
Bottom Right
Clip image from bottom right corner x value 0-255 0-100 0 0
Framing Y
Bo
ttom Right
Clip image from bottom right corner y value 0-255 0-100 0 0
Framing X
Bo
ttom Left
Clip image from bottom left corner x value 0-255 0-100 0 0
Framing
Bo
ttom Left
Clip image from bottom left corner y value 0-255 0-100 0
0
Global Viewpoint
Viewpoint
Mode
Perspective View, Spherical Coordinates
0 0
Look at point: center of universe 0 0
Look at point: graphic 1 1
NALook at point: graphic 2 2
Look at point: graphic 3
3
Perspective View, Cartesian Coordinates
Look at point: center of universe 4
NA
Look at point: graphic 1 5
Look at point: graphic 2 6
Look at point: graphic 3
7
Orthogonal View, Cartesian Coordinates
Look at point: center of universe 8
NA
Look at point: graphic 1 9
Look at point: graphic 2 10
Look at point: graphic 3
11
Perspective View, Spherical Coordinates
Look at point: graphic 4 12
NA
Look at point: graphic 5 13
Look at point: graphic 6 14
Look at point: graphic 7 15
Look at point: graphic 8 16
Look at point: graphic 9
17
Perspective View, Cartesian Coordinates
Look at point: graphic 4 18
NA
Look at point: graphic 5 19
Look at point: graphic 6 20
Look at point: graphic 7 21
Look at point: graphic 8 22
Look at point: graphic 9
23
Parameter Description
DMX Value Default
Dec. % Dec. %
