APPENDIX A
DMX Protocol
340 DL.3 Digital Light User Manual
Viewpoint
Mode
Orthogonal View, Cartesian Coordinates
0 0
Look at point: graphic 4 24
NA
Look at point: graphic 5 25
Look at point: graphic 6 26
Look at point: graphic 7 27
Look at point: graphic 8 28
Look at point: graphic 9
29
Additional Effects
Reserved 30-127
Variable Edge Blend 128
Reserved 12-255
Viewpoint
X Po
sition
Maximum horizontal angle clockwise 0 0-
32768 50Center 32768 50
Maximum horizontal angle counterclockwise 65535 100
Viewpoint
Y Po
sition
Maximum Vertical angle clockwise 0 0-
32768 50Center 32768 50
Maximum Vertical angle counterclockwise 65535 100
Viewpoint
Z Po
sition
(Zoom)
Maximum distance from origin in front of view target 0 0
32768 50Center 32768 50
Maximum distance from origin behind view target 65535
100
Global Control
Global
Co
ntrol
(A number in
p
arenthesis is
the minimum
number of
consecutive
times a DMX
value must be
received from
a controller
before the
operation
begins.)
No control selected. Safe 0 0
0 0
Reserved 1-119
NA
Axon Shutdown when Intensity = 0 (80) 120-130
Reserved 131-144
Reset when Intensity = 0 (80) 145-149
Reserved 150-251
Spherical Control Statistics (Global Control Modifier
Parame
ter selects text color)
252
All-in-One displays an array that includes each layer’s
out
put, each layer’s combined output, and any spherical
effects applied.
253
Performance Statistics 254
On-screen Statistics 255
Reserved
4-255
Parameter Description
DMX Value Default
Dec. % Dec. %
