APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 341
Global
Control
Modifier
All-in-one Combined Quadrant (Global Control Channel = 253)
0 0
Displays each defined Graphic Object with no effects
app
lied
0 0
Displays the first effect (if any) applied to any defined
Gra
phic Object
1
NA
Displays the second effect (if any) applied to any defined
Gra
phic Object
2
Displays the third effect (if any) applied to any defined
Gra
phic Object
3
Displays the fourth effect (if any) applied to any defined
Gra
phic Object
4
Displays the fifth effect (if any) applied to any defined
Gra
phic Object
5
Displays the sixth effect (if any) applied to any defined
Gra
phic Object
6
Displays the seventh effect (if any) applied to any
def
ined Graphic Object
7
Displays the eighth effect (if any) applied to any defined
Gra
phic Object
8
Displays the ninth effect (if any) applied to any defined
Gra
phic Object
9
Reserved. Reverts to raw image display
10-255
On-screen Statistics (Global Control Channel = 252 or 255)
Text color = gray 0
NA
Text color = red 1
Text color = blue 2
Text color = green
3
On-screen Statistics (Global Control Channel = 254)
Controls opacity from full to transparent 0-255
NA
Parameter Description
DMX Value Default
Dec. % Dec. %
