APPENDIX A
DMX Protocol
342 DL.3 Digital Light User Manual
GRAPHIC OBJECT FUNCTIONS
Opacity
Selects transparency level from completely transparent
(0) to opaque (255)
0-255 0-100 0
0
Graphic Content Definition
3-D Object
F
ile
No selection 0 0
1 1
First Stock 3-D Object (flat plane) 1 1
Additional Stock 3-D Objects 2-149
NAFirst User 3-D Objects 150
Additional User Objects 151-255
Media Folder
No selection 0
NA 0 0
HES Folder 1 1
HES Folders 2- 40 2-40
First User Folder 41 41
User Folders 42-239 42-239
Reserved 240-254
Video capture. The Media File parameter selects S
V
ideo or SDI input. Other Media file values are ignored.
NOTE: SDI available with DL.3 and Axon only.
255
Media File
Media File Selection (Media Folder Channel = 0-254)
0 0
No selection 0 0
First Media File 1
NA
Additional Media Files 2-255
2-255
Video Capture Selection (Media Folder Channel = 0-255)
0 0
No Video capture source selected
0
0
SVideo capture source 1
NA
Standard Definition (SD) SDI capture source, if installed 2
SVideo capture source 2, if installed.
Available with Axon server only
3
SD SDI capture source 2, if installed.
Available with Axon server only
4
High Definition (HD) SDI source 1, if installed.
Available with Axon server only
5
High Definition (HD) SDI source 2, if installed.
Available with Axon server only
6
High Definition (HD) SDI source 3, if installed.
Available with Axon server only
7
High Definition (HD) SDI source 4, if installed.
Available with Axon server only
8
Parameter Description
DMX Value Default
Dec. % Dec. %
