DMX Protocol
DL.3 Digital Light User Manual 343
In Frame
Defines the beginning of a media file segment as a
percentage of the movie length
0-
65535
0-100 0 0
Out Frame
Defines the end of a Media File segment as a
perce
ntage of the movie length
0-
65535
0-100 65535 100
Play Mode
Play forward looping continuously 0 0
0 0
Play forward once and hold on the last frame 1
NA
Pause 2
Play forward if opacity > 0, hold on last frame 3
Play forward if opacity > 0, looping continuously 4
Pause and rewind to In Frame 5
Scrub (Display) the selected In Frame 6
Scrub (Display) the selected Out Frame 7
Scrub (Display) the selected In Frame with statistics 8
Scrub (Display) the selected Out Frame with statistics 9
Reserved 10-255 3-100
Play Speed
Normal Speed 0 0
128 50
Slow speeds from slowest toward normal 1-127 1-49
Normal Speed 128 50
Faster than Normal to Fastest 129-255
51-100
Graphic Synchronization
Sync Type
No selection 0 0
0 0
Sync to Graphic 1 movie time 1
NA
Sync to Graphic 2 movie time 2
Sync to Graphic 3 movie time 3
Sync to Object 1 rotation 4
Sync to Object 2 rotation 5
Sync to Object 3 rotation 6
Sync to reverse Object 1 rotation 7
Sync to reverse Object 2 rotation 8
Sync to reverse Object 3 rotation 9
Sync to Graphic 1 movie time and Object 1 rotation 10
Sync to Graphic 2 movie time and Object 2 rotation 11
Sync to Graphic 3 movie time and Object 3 rotation 12
Sync to Graphic 1 movie time and Object 1 reverse
rot
ation
13
Sync to Graphic 1 movie time and Object 2 reverse
rot
ation
14
Parameter Description
DMX Value Default
Dec. % Dec. %
