APPENDIX A
DMX Protocol
344 DL.3 Digital Light User Manual
Sync Type
Sync to Graphic 1 movie time and Object 3 reverse
rotation
15
NA 0 0
Sync to Graphic 4 movie time 16
Sync to Graphic 5 movie time 17
Sync to Graphic 6 movie time 18
Sync to Graphic 7 movie time 19
Sync to Graphic 8 movie time 20
Sync to Graphic 9 movie time 21
Sync to Object 4 rotation 22
Sync to Object 5 rotation 23
Sync to Object 6 rotation 24
Sync to Object 7 rotation 25
Sync to Object 8 rotation 26
Sync to Object 9 rotation 27
Sync to Object 4 reverse rotation 28
Sync to Object 5 reverse rotation 29
Sync to Object 6 reverse rotation 30
Sync to Object 7 reverse rotation 31
Sync to Object 8 reverse rotation 32
Sync to Object 9 reverse rotation 33
Sync to Graphic 4 movie time and Object 4 rotation 34
Sync to Graphic 5 movie time and Object 5 rotation 35
Sync to Graphic 6 movie time and Object 6 rotation 36
Sync to Graphic 7 movie time and Object 7 rotation 37
Sync to Graphic 8 movie time and Object 8 rotation 38
Sync to Graphic 9 movie time and Object 9 rotation 39
Sync to Graphic 4 movie time and Object 4 reverse
ro
tation
40
Sync to Graphic 5 movie time and Object 5 reverse
ro
tation
41
Sync to Graphic 6 movie time and Object 6 reverse
ro
tation
42
Sync to Graphic 7 movie time and Object 7 reverse
ro
tation
43
Sync to Graphic 8 movie time and Object 8 reverse
ro
tation
44
Sync to Graphic 9 movie time and Object 9 reverse
ro
tation
45
Reserved. Defaults to mode 0, no selection.
16- 255
Parameter Description
DMX Value Default
Dec. % Dec. %
