APPENDIX A
DMX Protocol
DL.3 Digital Light User Manual 347
Graphic
Effect Mode
1, 2 & 3
Solarize (if color value < DMX, color = 0). Mod1 = red,
Mod2 = green, Mod3 = blue.
11
NA 0 0
Solarize 4 (if color value > DMX, color = 0). Mod1 = red,
Mod2 = green, Mod3 = blue.
12
DotP and Resample. Mod1, Mod2 and Mod3 control
resamp
ling.
13
Color Cycle (DMX value controls cycle speed)
Mod1 = red, Mod2 = green, Mod3 = blue.
14
All or Nothing (Color value greater than Mod value,
col
or = 255, else color = 0)
Mod1 = red, Mod2 = green, Mod3 = blue.
15
Solid Color RGB. Mod1 = red, Mod2 = green,
Mod3 = blue.
16
RGB Invert. Mod1 = red to cyan, Mod2 = green to
mage
nta, Mod3 = blue to yellow
17
RGB Invert & Swap to GBR. Mod1 = red to magenta,
Mod2 = green to yellow, Mod3 = blue to cyan
18
RGB Invert & Swap to BRG. Mod1 = red to yellow,
Mod2 = green to cyan, Mod3 = blue to magenta
19
Edge Detect Color. Mod1 = horizontal size,
Mod2 =
vertical search size, Mod3 = comparison
threshold
20
Edge Detect B/W Mod1 = horizontal size,
Mod2 = vertical search size, Mod3 = comparison
th
reshold
21
Texture Ripple, Horizontal. Mod1 = size, Mod2 = rate,
Mod3 = offset
22
Texture Ripple, Vertical. Mod1 = size, Mod2 = rate,
Mod3 = offset
23
Texture Ripple, Circular. Mod1 = size, Mod2 = rate,
Mod3 = offset
24
Texture Ripple, Asymmetrical Circular. Mod1 = size,
Mod2 = rate, Mod3 = offset
25
Transparent Color Fine. Select key color. Mod1 = red,
Mod2
= green, Mod3 = blue
26
Transparent Color Medium. Select key color.
Mod1 = red, Mod2 = green, Mod3 = blue
27
Transparent Color Coarse. Select key color.
Mod1 = red, Mod2 = green, Mod3 = blue
28
Transparent Color Invert, Fine. Select key color.
Mod1 = red, Mod2 = green, Mod3 = blue
29
Transparent Color Invert, Medium. Select key color.
Mod1 = red, Mod2 = green, Mod3 = blue
30
Parameter Description
DMX Value Default
Dec. % Dec. %
