Operation Manual - Routing Protocol
Quidway S3500 Series Ethernet Switches Chapter 3 RIP Configuration
Huawei Technologies Proprietary
3-11
3.3 Displaying and Debugging RIP
After the above configuration, execute display command in any view to display the
running of the RIP configuration, and to verify the effect of the configuration. Execute
debugging command in user view to debug the RIP module. Execute reset command
in RIP view to reset the system configuration parameters of RIP.
Table 3-17 Displaying and debugging RIP
Operation Command
Display the current RIP running state and
configuration information.
display rip
Enable the RIP debugging information
debugging rip packet
Disable the RIP debugging information
undo debugging rip packet
Enable the debugging of RIP receiving packet
debugging rip receive
Disable the debugging of RIP receiving packet
undo debugging rip
receive
Enable the debugging of RIP sending packet
debugging rip send
Disable the debugging of RIP sending packet
undo debugging rip send
Reset the system configuration parameters of RIP
reset
3.4 Typical RIP Configuration Example
3.4.1 Networking requirements
As shown in the following figure, the S3500 Series Ethernet Switches C connects to the
subnet 117.102.0.0 through the Ethernet port. The Ethernet ports of S3500 Series
Ethernet Switches A and Switch B are respectively connected to the network
155.10.1.0 and 196.38.165.0. Switch C, Switch A and Switch B are connected via
Ethernet 110.11.2.0. Correctly configure RIP to ensure that Switch C, Switch A and
Switch B can interconnect.
