Operation Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 1 ACL Configuration
Huawei Technologies Proprietary
1-4
Item Value range
Named advanced ACL.
-
Named Layer-2 ACL.
-
Named user-defined ACL.
-
The sub items of an ACL 0 to 127
 Note:
S3526 Series and S3552 Series Ethernet Switches don’t support user-defined ACL.
S3526E Ethernet Switch supports all kinds of ACL.
Table 1-3 Quantitative limitation to the ACL of S3552
Item Value range Maximum Number ACL Activated
Numbered basic ACL.
2000 to 2999
Numbered advanced ACL. 3000 to 3999
Numbered Layer-2 ACL.
4000 to 4999
Named basic ACL.
-
Named advanced ACL.
-
Named Layer-2 ACL.
-
64 per 100M-port
512 per 1000M-port
The sub items of an ACL 0 to 127 -
Maximum sub items for all
ACL (sum of all ACL’s sub
items)
-
1024
One rule can be delivered to hardware by multiple QoS functions, which means the
switch can perform many actions on a certain data stream. No matter how many QoS
functions use the rule, the switch considers that only one rule is delivered to hardware.
For example, up to 64 rules can be delivered at the 100Base-T port Ethernet0/1, rule 0
of ACL 1 is delivered to this port by traffic policing and priority tag functions separately.
The switch considers only one rule is delivered and 63 other rules can be delivered at
this port.
1.2 Configuring ACL of S3526
S3526 Series Ethernet Switches include S3526, S3526 FM, and S3526 FS switches.
ACL configuration includes:
