Quidway S3500 Series Ethernet Switches Chapter 9 Multicast VLAN
Huawei Technologies Proprietary
9-3
Item Command Description
Defining the type of the
port to hybrid
port link-type hybrid
Required
Specifying VLANs for
the port
port hybrid vlan vlan_id_list
{ tagged | untagged }
Required
To cancel the configurations, use the corresponding undo commands.
 Note:
z The isolate vlan cannot be set to a multicast VLAN.
z Only one multicast VLAN can be specified for a port.
z The type of the ports connected with user terminals can only be hybrid.
9.3 Multicast VLAN Configuration Example
I. Network requirements
The devices and requirements are as follows:
Table 9-3 Devices and their requirements in the example
Device Role Description
Switch A Layer 3 switch
The IP address of the VLAN 20 interface is
168.10.1.1; The port E1/0/1 belongs to VLAN 20 and
is connected with the workstation.
VLAN 10 acts as a multicast VLAN.
The port E1/0/10 is connected with switch B.
Switch B Layer 2 switch
VLAN 2 includes the port E1/0/1, which is connected
with PC1; the VLAN 3 includes the port E1/0/2, which
is connected with PC2.
The port E1/0/10 is connected with switch A.
PC 1 User 1 PC1 is connected with switch B through port E1/0/1.
PC 2 User 2 PC2 is connected with switch B through port E1/0/2.
Perform the following multicast VLAN configuration to allow users in VLAN 2 and VLAN
3 to receive multicast streams through the multicast VLAN.
