Huawei Quidway S3500 Series User Manual

Operation Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 1 ACL Configuration
Huawei Technologies Proprietary
1-24
Table 1-27 Activating ACL
Operation Command
Activate an ACL
packet-filter inbound acl-rule
Deactivate an ACL
undo packet-filter inbound acl-rule
Only the rules including these elements defined in template can be sent to target
hardware and referenced for such QoS functions as packet filtering, traffic policing,
priority re-labeling. Otherwise, the rules cannot be activated on the hardware. The ACL
combined mode is following.
Table 1-28 Combined Mode of ACL
Combined Mode Value
All rules in IP ACL ip-group { acl-number | acl-name }
Only one rule in IP ACL ip-group { acl-number | acl-name } rule rule
All rules in Link ACL link-group { acl-number | acl-name }
Only one rule in Link ACL link-group { acl-number | acl-name } rule rule
All rules in IP ACL and
one rule in Link ACL
ip-group { acl-number | acl-name } link-group
{ acl-number | acl-name } rule rule
One rule in IP ACL and
one rule in Link ACL
ip-group { acl-number | acl-name } rule rule link-group
{ acl-number | acl-name } rule rule
One rule in IP ACL and
all rules in Link ACL
ip-group { acl-number | acl-name } rule rule link-group
{ acl-number | acl-name }
1.4.5 Displaying and Debugging ACL
After the above configuration, execute display command in any view to display the
running of the ACL configuration, and to verify the effect of the configuration. Execute
reset command in user view to clear the statistics of the ACL module.
Table 1-29 Displaying and debugging ACL
Operation Command
Display the status of the time
range
display time-range { all | name }
Display the detail information
about the ACL
display acl config { all | acl-number | acl-name }
Display the information about
the ACL running state
display acl running-packet-filter all
