Huawei Quidway S3500 Series User Manual

Operation Manual - STP
Quidway S3500 Series Ethernet Switches Chapter 1 MSTP Region-configuration
Huawei Technologies Proprietary
1-18
Table 1-10 Configure the max transmission speed on a port
Operation Command
Configure the max transmission speed
on a port.
stp interface interface-list transit-limit
packetnum
Restore the max transmission speed on
a port.
undo stp interface interface-list
transit-limit
II. Configure in Ethernet port view
Perform the following configuration in Ethernet port view.
Table 1-11 Configure the max transmission speed on a port
Operation Command
Configure the max transmission speed on a port.
stp transit-limit packetnum
Restore the max transmission speed on a port.
undo stp transit-limit
You can configure the max transmission speed on a port with either of the
above-mentioned measures. For more about the commands, refer to the Command
Manual.
This parameter only takes a relative value without units. If it is set too large, too many
packets will be transmitted during every Hello Time and too many network resourced
will be occupied. The default value is recommended.
By default, the max transmission speed on every Ethernet port of the switch is 3.
1.2.9 Configure a Port as an Edge Port
An edge port refers to the port not directly connected to any switch or indirectly
connected to a switch over the connected network.
You can configure a port as an edge port or non-edge port in the following ways.
I. Configure in system view
Perform the following configuration in system view.
Table 1-12 Configure a port as an edge port or a non-edge port
Operation Command
Configure a port as an edge port.
stp interface interface-list edged-port
enable
Configure a port as a non-edge port.
stp interface interface-list edged-port
disable
