Quidway S3500 Series Ethernet Switches Chapter 6 PIM-DM Configuration
Huawei Technologies Proprietary
6-4
6.1.4 Entering PIM View
To configure PIM-related global parameters, you need to enter PIM view.
Please perform the following configurations in system view.
Table 6-3 Entering PIM view
Operation Command
Enter PIM view
pim
Clear configurations in PIM view and return to system view
undo pim
6.2 Display and Debug PIM-DM
After the above configuration, execute display command in any view to display the
running of PIM-DM configuration, and to verify the effect of the configuration.
Execute debugging command in user view for the debugging of PIM-DM.
Table 6-4 Display and debug PIM-DM
Operation Command
Display the PIM multicast
routing table
display pim routing-table [ { { *g [ group-address
[ mask { mask-length | mask } ] ] | **rp [ rp-address
[ mask { mask-length | mask } ] ] } | { group-address
[ mask { mask-length | mask } ] | source-address
[ mask { mask-length | mask } ] } * } |
incoming-interface { interface-type interface-num
| interface-name | null } | { dense-mode |
sparse-mode } ] *
Display the PIM interface
information
display pim interface [ interface-type
interface-number ]
Display the information about
PIM neighboring routers
display pim neighbor [ interface interface-type
interface-number ]
Enable the PIM debugging
debugging pim common { all | event | packet |
timer }
Disable the PIM debugging
undo debugging pim common { all | event |
packet | timer }
Enable the PIM-DM
debugging
debugging pim dm { alert | all | mbr | mrt | timer |
warning | { recv | send } { all | assert | graft |
graft-ack | join | prune } }
Disable the PIM-DM
debugging
undo debugging pim dm { alert | all | mbr | mrt |
timer | warning | { recv | send } { all | assert | graft
| graft-ack | join | prune } }
