Operation Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 2 QoS Configuration
Huawei Technologies Proprietary
2-4
3) Delay bounded WRR
Comparing to the common WRR, the Delay bounded WRR also guarantee the packets
in the highest-priority queue to leave the queue before the configured delay.
2.1.9 Traffic Mirroring
The traffic mirroring function is carried out by copying the specified data packets to the
monitoring port for network diagnosis and troubleshooting.
2.1.10 Traffic Counting
With the flow-based traffic counting, you can request a traffic count to count and
analyze the packets.
2.2 Configuring QoS of S3526
QoS configuration includes:
z Setting port priority
z Configuring trust packet priority
z Packet filter
z Priority tag
z Queue scheduling
z Traffic mirroring
z Traffic statistics
S3526 has some restrictions on ACL configuration in implementing QOS function using
traffic classification. The restriction details are listed in the following table.
Table 2-1 ACL configuration restriction for QoS function on S3526
QoS function Implementation Restrictions on ACL configuration
Packet filter
packet-filter
{ ip-group
{ acl-number |
acl-name } [ rule rule ] |
link-group
{ acl-number |
acl-name } [ rule rule ] }
Packet filter only supports using the
ACL of deny operation.
The Layer-2 ACL supports using the
rules of MAC-MAC, MAC-PORT,
PORT-PORT, MAC-ANY, ANY-MAC,
PORT-ANY and ANY-PORT.
The Layer-3 ACL supports using the
rules of IP-IP, IP-NET, NET-NET,
IP-ANY, ANY-IP, NET-ANY and
ANY-NET.
