Operation Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 1 ACL Configuration
Huawei Technologies Proprietary
1-5
z Configuring the time range
z Defining ACL
z Activating ACL
The above three steps had better be taken in sequence. Configure time range first and
then define ACL (using the defined time range in the definition), followed activating ACL
to validate it.
1.2.1 Configuring the Time-Range
The process of configuring a time-range includes the steps of configuring the
hour-minute range, date ranges and period range. The hour-minute range is expressed
in the units of minute, hour. Date range is expressed in the units of minute, hour, date,
month and year. The periodic time range is expressed in the day of the week.
You can use the following command to set the time range by performing the following
configuration in the system view.
Table 1-4 Setting the absolute time range
Operation Command
Set the
absolute time
range
time-range time-name { start-time to end-time days-of-the-week
[ from start-time start-date ] [ to end-time end-date ] | from
start-time start-date [ to end-time end-date ] }
Delete the
absolute time
range
undo time-range time-name [ start-time to end-time
days-of-the-week [ from start-time start-date ] [ to end-time
end-date ] | from start-time start-date [ to end-time end-date ] ]
When the start-time and end-time are not configured, it will be all the time for one day.
The end time shall be later than the start time.
When end-time end-date is not configured, it will be all the time from now to the date
which can be displayed by the system. The end time shall be later than the start time.
1.2.2 Defining ACL
Huawei Switches support several kinds of ACLs. Here we will introduce how to define
these ACLs.
Defining ACL by following the steps below:
1) enter the corresponding ACL view
2) add a rule to the ACL
You can add multiple rules to one ACL.
