Operation Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 1 ACL Configuration
Huawei Technologies Proprietary
1-9
S3526 has some restrictions on ACL configuration in implementing QOS function using
traffic classification. The restriction details are listed in the following table.
Table 1-9 ACL configuration restriction for QoS function on S3526
QoS
function
Implementation Restrictions on ACL configuration
Packet
filter
packet-filter
{ ip-group
{ acl-number |
acl-name } [ rule
rule ] | link-group
{ acl-number |
acl-name } [ rule
rule ] }
Packet filter only supports using the ACL of deny
operation.
The Layer-2 ACL supports using the rules of
MAC-MAC, MAC-PORT, PORT-PORT,
MAC-ANY, ANY-MAC, PORT-ANY and
ANY-PORT.
The Layer-3 ACL supports using the rules of
IP-IP, IP-NET, NET-NET, IP-ANY, ANY-IP,
NET-ANY and ANY-NET.
Note:
z The Layer-3 ACL includes the advanced ACL.
z In the description of the rules: MAC----MAC address, PORT----the switch port,
IP----the host IP address, ANY----any MAC address in Layer-2 ACL and any IP
address in Layer-3 ACL, NET----the segment IP address. The MAC, IP, ANY, NET
and PORT before the character “-” represent the source addresses or receive port;
the ones behind are the destination addresses or transmit port.
z MAC-MAC stands for a Layer-2 ACL rule from source MAC address to destination
MAC address, such as “rule 0 permit ingress 00e0-fc01-0101 1 egress
00e0-fc01-0102 1 time-range huawei ”.
z PORT-PORT stands for a Layer-2 ACL rule from received ethernet port to sent
ethernet port, such as “rule 0 permit ingress interface ethernet0/1 egress interface
ethernet 0/2 time-range huawei ”.
z MAC-PORT stands for a Layer-2 ACL rule from source MAC address to sent
ethernet port, such as “rule 0 permit ingress 00e0-fc01-0101 1 egress interface
ethernet 0/1 time-range huawei ”.
z IP-IP stands for lay-3 ACL rules from source host IP address to destination host IP
address (the wildcard parameter can only be 0) , such as “rule 0 permit ip source
1.1.1.1 0 destination 2.2.2.2 0 time-range huawei”.
z NET-NET stands for lay-3 ACL rules from source segment IP address to destination
segment IP address (the wildcard parameter can not be 0), such as “rule 0 permit ip
source 1.1.1.1 0.0.255.255 destination 2.2.2.2 0.0.255.255 time-range huawei”.
z MAC-any stands for lay-2 ACL rule from source MAC address to any destination
MAC address, such as “rule 0 permit ingress 00e0-fc01-0101 1 egress any
time-range huawei”, and so do any-MAC, IP-any, any-IP, NET-any and any-NET
rules.
