Operation Manual - QoS/ACL
Quidway S3500 Series Ethernet Switches Chapter 2 QoS Configuration
Huawei Technologies Proprietary
2-22
Traffic policing actions include re-assigning service group based on DSCP +
conform-level to service map, re-assigning traffic’s 802.1p precedence based on TC +
conform-level to CoS map, etc. You may configure the mentioned two maps as needed.
I. Configuring maps
You may configure DSCP + conform-level to service and TC + conform-level to CoS
maps using commands listed in the following table.
Perform the following configuration in system view.
Table 2-32 Configuring maps
Operation Command
Access conform-level view from
system view.
qos conform-level conform-level-value
Configure DSCP + conform-level to
service map in conform-level view.
dscp dscp-list : dscp-value CoS-value
local-precedence-value drop-precedence
Restore the default DSCP +
conform-level to service map
setting in conform-level view.
undo dscp [ dscp-list ]
Configure TC + conform-level to
CoS map in conform-level view.
local-precedence CoS-value0 CoS-value1
CoS-value2 CoS-value3 CoS-value4
CoS-value5 CoS-value6 CoS-value7
Restore the default TC +
conform-level to CoS map setting
in conform-level view.
undo local-precedence
By default, the system provides default map settings.
II. Configuring traffic policing
You may configure traffic policing using the command described in the following table.
Perform the following configuration in Ethernet interface view.
Table 2-33 Configuring traffic policing
Operation Command
Configure
traffic-based traffic
policing.
traffic-limit inbound acl-rule cir cbs ebs [ pir ] [ conform
{ { remark-cos | remark-drop-priority }* |
remark-policed-service } ] [ exceed { forward | drop } ]
Disable traffic-based
traffic policing.
undo traffic-limit inbound acl-rule
Before you can configure traffic-based traffic policing, you should configure the ACLs
for this purpose in addition to the DSCP + conform-level to service and TC +
conform-level to CoS maps.
