Quidway S3500 Series Ethernet Switches Chapter 1 IP Address Configuration
Huawei Technologies Proprietary
1-2
Table 1-1 IP address classes and ranges
Network
class
Address
range
IP network
range
Note
A
0.0.0.0 to
127.255.2
55.255
1.0.0.0 to
126.0.0.0
Host ID with all the digits being 0
indicates that the IP address is the
network address, and is used for
network routing.
Host ID with all the digits being 1
indicates the broadcast address, i.e.
broadcast to all hosts on the network.
IP address 0.0.0.0 is used for the host
that is not put into use after starting up.
The IP address with network number as
0 indicates the current network and its
network can be cited by the router
without knowing its network number.
Network ID with the format of 127.X.Y.Z
is reserved for self-loop test and the
packets sent to this address will not be
output to the line. The packets are
processed internally and regarded as
input packets.
B
128.0.0.0
to
191.255.2
55.255
128.0.0.0 to
191.254.0.0
Host ID with all the digits being 0
indicates that the IP address is the
network address, and is used for
network routing.
Host ID with all the digits being 1
indicates the broadcast address, i.e.
broadcast to all hosts on the network.
C
192.0.0.0
to
223.255.2
55.255
192.0.0.0 to
223.255.254.
0
Host ID with all the digits being 0
indicates that the IP address is the
network address, and is used for
network routing.
Host ID with all the digits being 1
indicates the broadcast address, i.e.
broadcast to all hosts on the network.
D
224.0.0.0
to
239.255.2
55.255
None
Addresses of class D are multicast
addresses.
E
240.0.0.0
to
255.255.2
55.254
None
The addresses are reserved for future
use.
Other
addresses
255.255.2
55.255
255.255.255.
255
255.255.255.255 is used as LAN
broadcast address.
