Table 54: TX Matrix Plus Routing Engine RE-C2600 LEDs (continued)
DescriptionStateColorLabel
Indicates disk activity.On steadilyBlueSSD1
There is no disk activity.Off–
Indicates disk activity.On steadilyBlueSSD2
There is no disk activity.Off–
Indicates activity for the CompactFlash card.On steadilyGreenCF
There is no activity for the CompactFlash card.Off–
Related
Documentation
TX Matrix Plus Router Overview on page 43•
Check the Redundant Routing Engine Status from the Craft Interface CLI Output
Purpose To check the status of the redundant routing engine from the craft interface CLI output.
Action To view the Routing Engine status from the craft interface, use the following CLI command:
user@host> show chassis craft-interface
For M10i routers:
user@host> show chassis craft-interface
Red alarm: LED off, relay off
Yellow alarm: LED on, relay on
Routing Engine OK LED: On
Routing Engine fail LED: Off
FPCs 0 1
-------------
Green * *
Red . .
LCD screen:
+--------------------+
|waddle |
|1 Alarm active |
|Y: Backup RE Active |
| |
+--------------------+
For M20 routers:
user@host> show chassis craft-interface
Red alarm: LED off, relay off
Yellow alarm: LED off, relay off
Routing Engine OK LED: On
Routing Engine fail LED: Off
191Copyright © 2012, Juniper Networks, Inc.
Chapter 6: Monitoring the Routing Engine
