CHAPTER 24
Monitoring the CFEB
•
Checklist for Monitoring the CFEB on page 517
•
CFEB Overview on page 519
•
Monitor the CFEB Status on page 521
•
Check for CFEB Alarms on page 523
•
Verify CFEB Failure on page 526
•
Obtain CFEB Hardware Information on page 529
•
Return the CFEB on page 530
Checklist for Monitoring the CFEB
Purpose To monitor the Compact Forwarding Engine Board (CFEB), which provides route lookup,
filtering, and switching on incoming data packets, then directs outbound packets to the
appropriate interface for transmission to the network. (See Table 126 on page 517.)
The M7i router CFEB can process 8 million packets per second (Mpps); the M10i router
CFEB can process 16 Mpps.
The CFEB communicates with the Routing Engine using a dedicated 100-Mbps Fast
Ethernet link that transfers routing table data from the Routing Engine to the forwarding
table in the integrated ASIC. The link is also used to transfer from the CFEB to the Routing
Engine routing link-state updates and other packets destined for the router that have
been received through the router interfaces.
Action Table 126: Checklist for Monitoring the CFEB
Command or ActionMonitor CFEB Tasks
“Monitor the CFEB Status” on page 521
show chassis environment1. Display the CFEB Environmental Status
on page 521
show chassis cfeb2. Display the CFEB Detailed Status on
page 522
Look at the LEDs on the CFEB faceplate located
on the rear of the router above the power supplies.
3. Check CFEB LEDs on page 522
517Copyright © 2012, Juniper Networks, Inc.
