TX Matrix Plus Router SIBs
In the TX Matrix Plus router, one data switching plane consists of one or two TXP-F13
SIBs connected internally through the midplane to four TXP-F2S SIBs. For the TXP-4
configuration, there are a total of five data switching planes in the routing matrix. One of
the five data switching planes acts as a backup spare to the remaining data switching
planes. If faults are detected in an active data switching plane, the plane is taken offline,
and the backup spare plane is brought online. When a failed component is replaced and
brought online, the data switching plane in which it resides becomes the new backup
spare plane.
Related
Documentation
Checklist for Monitoring Redundant SIBs on page 649•
Display Redundant SIB Hardware Information
Purpose To display the redundant SIB hardware information.
Action Use the following command:
user@host> show chassis hardware
Sample Output
user@host> show chassis hardware
Item Version Part number Serial number Description
Chassis 20079 T640
[...Output truncated...]
SIB 0 REV 05 710-003980 HF9603 SIB-I8
SIB 1 REV 05 710-003980 HF9577 SIB-I8
SIB 2 REV 05 710-003980 HF9540 SIB-I8
SIB 3 REV 05 710-003980 HF9550 SIB-I8
SIB 4 REV 05 710-003980 HF9592 SIB-I8
Meaning The command output is for a T640 router. The command output displays the SIB slot
number, revision level, part number, serial number, and description. By default, SIB0 is
the redundant SIB.
Related
Documentation
Checklist for Monitoring Redundant SIBs on page 649•
Display SIB Redundancy Information
Purpose To gather information about the redundant SIB.
Action Use the following command:
user@host> show chassis sib
Sample Output
t320@host> show chassis sibsSlot State Uptime
0 Spare
1 Online 2 days, 7 hours, 10 minutes, 13 seconds
653Copyright © 2012, Juniper Networks, Inc.
Chapter 32: Monitoring Redundant SIBs
