Figure 307: TX Matrix Router Redundant Power Supplies

g006597

PEM 0

PEM 1

Two-Input 160-A DC Power supply

Three-Input 240-A DC Power supply

Documentation

Checklist for Monitoring Redundant Power Supplies on page 607•

TX Matrix Plus Redundant Power Supplies

The TX Matrix Plus router supports DC power only. The TX Matrix router has two

load-sharing DC power supplies located at the lower rear of the chassis in slots PEM0

and PEM1 (top to bottom) . The TX Matrix Plus router supports the seven-input 420-A

power supply. Figure 308 on page 619 shows the TX Matrix Plus router power supplies

and where they are installed in the chassis.

These two power supplies share the load evenly. If one power supply fails, the other

power supply can provide full power to the TX Matrix Plus router indefinitely.
