T640 Router Control Board
Figure 199 on page 373 shows the T640 router Control Board component of the host
subsystem.
Figure 199: T640 Router Control Board Component
T1600 Router Control Board
Figure 200 on page 373 shows the T1600 router Control Board component of the host
subsystem.
Figure 200: T1600 Router Control Board Component
TX Matrix Router Control Board
Figure 201 on page 374 shows the TX Matrix router Control Board component of the host
subsystem.
