Bottom Left Front fan OK Spinning at normal speed
Bottom Left Middle fan OK Spinning at normal speed
Bottom Left Rear fan OK Spinning at normal speed
Bottom Right Front fan OK Spinning at normal speed
Bottom Right Middle fan OK Spinning at normal speed
Bottom Right Rear fan OK Spinning at normal speed
Rear Tray Top fan OK Spinning at normal speed
Rear Tray Second fan OK Spinning at normal speed
Rear Tray Third fan OK Spinning at normal speed
Rear Tray Fourth fan OK Spinning at normal speed
Rear Tray Fifth fan OK Spinning at normal speed
Rear Tray Sixth fan OK Spinning at normal speed
Rear Tray Seventh fan OK Spinning at normal speed
Rear Tray Bottom fan OK Spinning at normal speed
Misc CIP 0 OK
CIP 1 OK
SPMB 0 OK
SPMB 1 OK
Top Left and Top Right refer to fans in the upper front fan tray; Bottom Left and Bottom
Right refer to fans in the lower front fan tray.
To display the status of the fans in the routing matrix (TX Matrix router and all T640
routers), issue the show chassis environment command. To display the status of the
fans in a specific T640 router, issue the show chassis environment lcc lcc-number
command, where lcc-number is the chassis ID of the router and can be from 0 through 3.
NOTE: The speed of the fans in the rear fan tray of a T640 router is affected
by the temperature of the T640-SIB main board (displayed as SIB n ), not
by the temperature of the T640-SIB mezzanine board [displayed as
SIB n (B)].
For the TX Matrix Plus router (see also “TX Matrix Plus Router Cooling System” on
page 337):
user@host> show chassis fan
sfc0-re0:
--------------------------------------------------------------------------
Item Status RPM Measurement
Fan Tray 0 Fan 1 OK 3450 Spinning at normal speed
Fan Tray 0 Fan 2 OK 3420 Spinning at normal speed
Fan Tray 0 Fan 3 OK 3480 Spinning at normal speed
Fan Tray 0 Fan 4 OK 3360 Spinning at normal speed
Fan Tray 0 Fan 5 OK 3360 Spinning at normal speed
Fan Tray 0 Fan 6 OK 3390 Spinning at normal speed
Fan Tray 1 Fan 1 OK 3420 Spinning at normal speed
Fan Tray 1 Fan 2 OK 3450 Spinning at normal speed
Fan Tray 1 Fan 3 OK 3450 Spinning at normal speed
Fan Tray 1 Fan 4 OK 3420 Spinning at normal speed
Fan Tray 1 Fan 5 OK 3480 Spinning at normal speed
Fan Tray 1 Fan 6 OK 3420 Spinning at normal speed
Fan Tray 2 Fan 1 OK 3420 Spinning at normal speed
Fan Tray 2 Fan 2 OK 3420 Spinning at normal speed
Fan Tray 2 Fan 3 OK 3420 Spinning at normal speed
Copyright © 2012, Juniper Networks, Inc.344
M Series and T Series Routers Monitoring and Troubleshooting Guide
