Keyence SV Series User Manual

5-32
5-6 Analog Monitor Setting
- SV Series User’s Manual -
COMMON PARAMETER SETTING
5
Output Data Adjustment
Analog monitor connector output data can be adjusted as follows. Analog monitor 1 and analog monitor 2 can be set
and adjusted respectively.
● Analog monitor 1 output
Analog monitor1 output =(-1) x (value of "Analog monitor 1" x "Analog monitor magnification 1" + "Analog monitor 1 offset voltage")
(OTH_15) (OTH_19) (OTH_17)
● Analog monitor 2 output
Analog monitor2 output = (-1) x (value of "Analog monitor 2" x "Analog monitor magnification 2" + "Analog monitor 2 offset voltage")
(OTH_16) (OTH_20) (OTH_18)
Analog monitor offset voltage and analog monitor
magnification be set through a parameter.
Parameter
type
Category Level Parameter name Setting range
Setting
Unit
Default
Enable
timing
OTH_17
Other Special
Analog monitor 1 offset voltage - 10000 to 10000 10 kHz 0
After
changing
OTH_18
Analog monitor 2 offset voltage - 10000 to 10000 0.1V 0
OTH_19
Analog monitor magnification 1 - 10000 to 10000 0.01 x 100
OTH_20
Analog monitor magnification 2 - 10000 to 10000 0.01 x 100
