1-4
- SV Series User’s Manual -
BEFORE USING
1-2 SV Series Model
Model Series of Servo Amplifier
Two types of servo amplifier is available: Cabling-saving MECHATROLINK-II type and pulse/analog input type.
Models depend on rated output and supply voltage.
Models of servo amplifier are shown as follows.
● MECHATROLINK-II type
● Pulse/analog input type
Do not use with a combination other than the above mentioned one.
SV
-
005 P 2
Rated output
005 : 50W
010 : 100W
020 : 200W
040 : 400W
075 : 750W
Supply voltage
1 : 100V
2 : 200V
Interface specification
L : MECHATROLINK-II type
P : Pulse/analog input type
100 : 1.0kW
150 : 1.5kW
200 : 2.0kW
300 : 3.0kW
500 : 5.0kW
Supply voltage Rated output Model of servo amplifier Supported servo motor
100V
50W SV-005L1 SV-005
100W SV-010L1 SV-010
200W SV-020L1 SV-020
400W SV-040L1 SV-040
200V
50W SV-005L2 SV-005
100W SV-010L2 SV-010
200W SV-020L2 SV-020
400W SV-040L2 SV-040
750W SV-075L2 SV-075
1.0kW SV-100L2 SV-100A
1.5kW SV-150L2 SV-150A
2.0kW SV-200L2 SV-200A
3.0kW SV-300L2 SV-300A
*1
*1 Rated values depend on connected servo amplifier. "2-3 Servo Amplifier Specifications", page 2-7.
5.0kW SV-500L2
SV-300A
*1
SV-500A
Supply voltage Rated output Model of servo amplifier Supported servo motor
100V
50W SV-005P1 SV-005
100W SV-010P1 SV-010
200W SV-020P1 SV-020
400W SV-040P1 SV-040
200V
50W SV-005P2 SV-005
100W SV-010P2 SV-010
200W SV-020P2 SV-020
400W SV-040P2 SV-040
750W SV-075P2 SV-075
1.0kW SV-100P2 SV-100A
1.5kW SV-150P2 SV-150A
2.0kW SV-200P2 SV-200A
3.0kW SV-300P2 SV-300A
*1
*1 Rated values depend on connected servo amplifier. "2-3 Servo Amplifier Specifications", page 2-7.
5.0kW SV-500P2
SV-300A
*1
SV-500A
Caution
To Next Page
