11-1 Access Window Overview
- SV Series User’s Manual -
ACCESS WINDOW
11
List of functions
Access Window includes the following nine modes.
Monitor To display status of servo amplifier.
Servo Mon ....................... Display internal status of servo amplifier.
IN Mon ............................. Display input status.
OUT Mon ......................... Display output status.
"Monitor Display", Page 11-6
Tuning To set up/execute tuning
Auto/Manu ....................... Display/set up auto/manual tuning
ClcInertia ......................... Set up/execute estimation of ratio of inertia moment
*
GainSrchIN ...........................Set up/execute Gain search PRO (w/o higher-level command).
*
GainSrchEX ........................ Set up/execute Gain search PRO (w/ higher-level command).
*
Gain Tuning ..................... Set up/execute Gain tuning PRO.
*
*Blanked in auto tuning.
"Tuning Setting", Page 11-6
Parameter To display/set up parameters.
System............................. Display/set up system parameters.
Position............................ Display/set up position parameters.
Speed .............................. Display/set up speed parameters.
Torque.............................. Display/set up toque parameters.
Tuning.............................. Display/set up tuning parameters.
Alarm ............................... Display/set up alarm parameters
*1
Other................................ Display/set up other parameters.
*1
I/O.................................... Display/set up I/O parameters.
*1
ML-2 ................................ Display/set up MECHATROLINK-II parameters.
*2
1 Blanked when the display level is "Basic".
2 MECHATROLINK-II type only
"Parameter Display/Setting", Page 11-7
Alarm To verify/reset alarm, verify/clear alarm logs and execute ABS encoder setting.
AlmReset ........................ Reset alarm.
ABS Setup....................... Execute ABS encoder setting.
AlmRecord....................... Up to 10 last alarms can be verified.
AlmRecClr ....................... Clear alarm logs.
"Alarm Reset", Page 11-8
SrvTestRun To execute servo JOG operation/pattern operation/Z-phase search.
ServoJOG........................ Execute servo JOG operation.
PTN Move........................ Execute pattern operation.
Org Search ...................... Execute Z-phase search.
"Servo Trial Run", Page 11-8
SetDisplay To set up Access Window display level/contrast/language.
"Diaplay Setting Change", Page 11-9
1.Servo
2.IN Mon
3.OUT Mon
1.Auto/Manu
2.ClcInertia
3.GainSrchIN
4.GainSrchEX
5.GainTuning
1.System
2.Position
3.Speed
4.Torque
5.Tuning
6.Alarm
7.Other
8.IO
9.ML-2
1.AlmReset
2.ABS Setup
3.AlmRecord
4.AlmRecClr
1.ServoJOG
2.PTN Move
3.Org Search
OTH_12
AW Contrast
6
