Keyence SV Series - Pattern Operation

9-4
9-1 Servo Trial Run
- SV Series User’s Manual -
SERVO TRIAL RUN FUNCTION
9
Pattern Operation
In this mode, pre-registered parameters are used for operation. This allows to check servo motor operation and
simple positioning without using the higher-level equipment.
Pattern operation is done in the position control mode.
 Parameter Setting
Note
Parameter
type
Category Level Parameter name Setting range
Setting
Unit
Default
Enable
timing
OTH_05 Other Extend Pattern Operation
0: [P]*n
1: [N]*n
2: [P]*n->[N]*n
3: [N]*n->[P]*n
4: ([P]->[N])*n
5: ([N]->[P])*n
- 0
After
changing
OTH_06 Other Extend
Pattern operating
move distance
1 to 1073741824
CMD
PLS
32768
OTH_07 Other Extend
Pattern operating
move speed
1 to 10000 min
-1
500
OTH_08 Other Extend
Pattern operate
accel/decel time
2 to 10000 ms 100
OTH_09 Other Extend
Pattern operating
waiting time
0 to 10000 ms 100
OTH_10 Other Extend
Pattern operate
movement times
*1
*1 When 0 is set, pattern operation is executed on a continuous basis. However, when OTH_05 is set to 2 or 3, 0
cannot be set up.
0 to 1000 Times 1
