1-5
1-2 SV Series Model
BEFORE USING
- SV Series User’s Manual -
Model Series of Servo Motor
Models of servo motor depend on rated output, whether or not equipped with electromagnetic brake, shape of axis
end and encoder type.
Models of servo motor are shown as follows.
Type of servo motor
M : Standard motor
B : Electromagnetic brake motor
Axis type
S : Straight axis
K : Axis with keyway
Encoder type
A : 20-bit ABS encoder
C : 20-bit INC encoder
Applicable capacity of
005 : 50W
010 : 100W
020 : 200W
040 : 400W
075 : 750W
SV
-
M
005
A
K
servo amplifier
100 : 1.0kW
150 : 1.5kW
200 : 2.0kW
300 : 3.0kW
500 : 5.0kW
Model Model/Rated output
Motor type
Axis type Encoder 100W 100W 200W 400W 750W
Standard motor
Straight axis
INC
SV-M005CS SV-M010CS SV-M020CS SV-M040CS SV-M075CS
ABS
SV-M005AS SV-M010AS SV-M020AS SV-M040AS SV-M075AS
Axis with keyway
INC
SV-M005CK SV-M010CK SV-M020CK SV-M040CK SV-M075CK
ABS
SV-M005AK SV-M010AK SV-M020AK SV-M040AK SV-M075AK
Electromagnetic
brake motor
Straight axis
INC
SV-B005CS SV-B010CS SV-B020CS SV-B040CS SV-B075CS
ABS
SV-B005AS SV-B010AS SV-B020AS SV-B040AS SV-B075AS
Axis with keyway
INC
SV-B005CK SV-B010CK SV-B020CK SV-B040CK SV-B075CK
ABS
SV-B005AK SV-B010AK SV-B020AK SV-B040AK SV-B075AK
Model Model/Applicable capacity of servo amplifier
Motor type
Axis type Encoder 1.0kW 1.5kW 2.0kW 3.0kW 5.0kW
Standard motor
Straight axis ABS
SV-M100AS SV-M150AS SV-M200AS SV-M300AS
*1
*1 Rated values depend on connected servo amplifier. "2-3 Servo Amplifier Specifications", page 2-7.
SV-M500AS
SV-M300AS
*1
Axis with keyway ABS
SV-M100AK SV-M150AK SV-M200AK SV-M300AK
*1
SV-M500AK
SV-M300AK
*1
Electromagnetic
brake
motor
Straight axis ABS
SV-B100AS SV-B150AS SV-B200AS SV-B300AS
*1
SV-B500AS
SV-B300AS
*1
Axis with keyway ABS
SV-B100AK SV-B150AK SV-B200AK SV-B300AK
*1
SV-B500AS
SV-B300AS
*1
To Next Page
