2-4 Servo Motor Specifications
CONFIGURATION & SPECIFICATIONS
2
- SV Series User’s Manual -
Electromagnetic Brake Specifications
The release/operating time of electromagnetic brake vary depending on the discharge circuit.
Model SV-B005 SV-B010 SV-B020 SV-B040 SV-B075
Capacity [W] 5.5 5.5 6 6 6.5
Rated voltage 24 VDC 0% to +10%
Rated current [A]
(at 20°C)
0.23 0.23 0.25 0.25 0.27
Coil resistance [Ω]
(at 20°C)
103 103 97.4 97.4 87.7
Holding torque [N·
m]
0.159 0.318 0.637 1.27 2.39
Release time [ms] 60 60 60 60 80
Operating time [ms] 100 100 100 100 100
Model SV-B100A SV-B150A SV-B200A SV-B300A SV-B500A
Capacity [W] 10 10 10 18.5 18.5
Rated voltage 24 VDC 0% to +10%
Rated current [A]
(at 20°C)
0.41 0.41 0.41 0.77 0.77
Holding torque [N·
m]
12.7 19.6 19.6 43.1 43.1
Release time [ms] 100 100 100 170 170
Operating time
[ms]
80 80 80 100 100
Note
