1-1 SV Series Configuration
About SV Series
SV series is an AC servo system consisting of servo amplifiers and motors.
Two types of servo amplifier are available: Cabling-saving MECHATROLINK-II type and Pulse/analog input type.
● MECHATROLINK-II type
MECHATROLINK-II type servo amplifier refers to the AC servo system that can be connected with servo amplifiers
using a dedicated cable via MECHATROLINK-II motion field network.
For example, control based on MECHATROLINK-II communication can be performed by combining and configuring KV-5000/
3000 series and KV-ML16V positioning/motion unit as follows.
● Pulse/analog input type
Pulse/analog input type amplifier can perform position control via the pulse commands from higher-level equipment,
or perform speed/torque control via analog/parameter commands.
For example, positioning control can be performed by combining and configuring KV-MC40V/MC20V positioning/
motion unit as follows .
SV series
MECHATROLINK-II
peripheral equipment
MECHATROLINK-II
terminator
Up to 16
MECHATROLINK-II
KV-ML16V
positioning/motion unit
MECHATROLINK-II
terminator (Built-in)
KV-HTC8
connector adaptor unit
with terminal block
KV-HC4
connecting cable
for motor driver
KV-HC1
connecting cable
for positioning unit
KV-MC40V/MC20V
positioning/motion unit
