Keyence SV Series User Manual

8-5
8-1 Tuning Overview and Operations
TUNING
8
- SV Series User’s Manual -
Conditions for Tuning
The following conditions must be met to use individual tuning functions.
Function Working conditions
Auto tuning
Auto tuning response setting
• Auto tuning mode
• Position/speed control mode
• Motorless test operation not used
Parameter mapping
Estimation of ratio of inertia moment
• Manual tuning mode
• In servo OFF status
• Position/speed control mode
• Motorless test operation not used
• Auto gain switching set to "Disable"
• Alarm/warning not occur
• Non-limit switch status
• Movement distance set to above servo motor shaft x0.5
revolution Gain 2 not used
Gain search PRO
W/o higher-level command
• Manual tuning mode
• In servo OFF status
• Position/speed control mode
• Motorless test operation not used
• Automatic gain switching is set to "not used"
• Alarm/warning not occur
• Non-limit switch status
• Movement distance set to above servo motor shaft x0.5
revolution Gain 2 not used
W/ higher-level command
• Manual tuning mode
• Position control mode
• Motorless test operation not used
• Auto gain switching set to "Disable"
• Alarm/warning not occur
• Non-limit switch status
• In servo ON status
• Gain 2 not used
Gain tuning PRO
• Manual tuning mode
• Motorless test operation not used
• Only stability (L) and
stability (H) can be used in speed /torque control mode

Keyence SV Series Specifications

General

Display	LCD
Output Type	Digital, Analog
Power Supply	24V DC
Communication	Ethernet, RS-232, RS-485
Series	SV Series
Programming Language	Ladder Logic
Mounting	Panel mounting
Operating Temperature	0 to +50°C
Storage Temperature	-20 to +60°C
Vibration Resistance	10 to 55 Hz
Shock Resistance	30G
