Keyence SV Series User Manual

2-2
CONFIGURATION & SPECIFICATIONS
2
- SV Series User’s Manual -
2-1 Check the Package Contents
Take out servo amplifier and servo motor from the packing box, and verify that the following accessories are enclosed.
Please check the models and combination of the servo amplifier and motor.
"1-2 SV Series Model", Page 1-4
Packages Attached with the Product
The following accessories should be supplied together with the product. Please check if the accessories are complete.
■ Servo amplifier
● Packages attached with the product
• The terminating set for the terminal block is also included with the 5kW servo amplifier (SV-500 □ 2).
• Since the terminals of servo amplifiers above 2kW (SV-200□2/300□2/500 □ 2) are screw type,
connectors and handles are not included with it.
● Nameplate
 Servo amplifier
 User's Manual
200V
type
100V
type
□ Power connector of main circuit/control circuit
*Integrated with the servo amplifier at ex-factory.
User’s Manual
□ Wiring lever for connector □ Motor power connector
Note
KEYENCE CORPORATION
必ず取扱説明書を読み指示に従ってください。
Read manual carefully and follow the instructions.
通電中および電源オフ後、５分間端子部に触れないでください。
感電の恐れがあります。
Disconnect all power supply and wait 5min.
before servicing. May cause electric shock.
ヒートシンクに触れないでください。
火傷の恐れがあります。
Do not touch heatsink. May cause burn.
必ずアース線を接続してください。
Use proper grounding techniques.
注意
CAUTION
危険
WARNING
AC SERVO
MODEL
SV-005L2
INPUT 3PH 200-230V 50/60Hz 0.3A
OUTPUT 3PH 0-230V 0-400Hz 0.66A 50W
SURROUNDING AIR TEMPERATURE 0-55°C
No. D00000000000000
MADE IN JAPAN
00000 - 0 - 0 D
Model
Input power supply
Motor output
Operating temperature
