Keyence SV Series User Manual

A-55
A-5MECHATROLINK-II Communication Commands
APPENDIX
- SV Series User’s Manual -
Connection request (0EH)[CONNECT]
To establish a MECHATROLINK-II connection, and the communication mode is set to "COM_MOD".
Available phase : Phase 1
Type of command : non-sync type
Reading cycle : > Communication period, < 5s
Sub command : Can't use
If the following warning appears, command will be ignored.
• When COM_MOD out of setting range
• When COM_TIM out of setting range
• When transmission speed is set to "10Mbps" and VER=21H do not meet
• When transmission byte is 17 bytes and SUBCMD=1
• When KV-ML/MC setting tool (KV MOTION+), SV series setting software or access window is being
operated.
Only CONNECT/DISCONNECT/NOP commands can be accepted by servo amplifier before connection
establishment.The response is NOP when receiving other commands.
■The relationship between transmission period and communication period
The relationship between MECHATROLINK-II transmission period and allowed communication period as well as
number of connections are as follows.
Parameters read (01H)[PRM_RD]
To read parameters of servo amplifier.
Available phase : Phase 2 and Phase 3
Type of command : non-sync type
Reading cycle : < 200ms
Sub command : Can't use
If the following warning appears, command will be ignored.
• When the number set up in the No. field is beyond the range ("data setting alarm 1 (beyond data range)"
(94A)) .
• When SIZE mismatch ("Data setting warning 4 (parameter size)" (94D))
Byte 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Command 03H 0EH - VER COM_MODE COM_TIME - WDT
Response 01H 0EH ALARM STATUS VER COM_MODE COM_TIME - RWDT
Note
Transmissio
n period
Allowed communication period
Number of transmission
bytes
17byte 32byte
Number of connected
stations
0.25ms 0.25ms to 8.00ms (0.25ms unit) 2 1
0.50ms 0.50ms to 16.00ms (0.50ms unit) 7 4
1.00ms 1.00ms to 32.00ms (1.00ms unit) 15 9
1.50ms 1.50ms to 32.00ms (1.50ms unit) 23 15
2.00ms 2.00ms to 32.00ms (2.00ms unit) 30 21
2.50ms 2.50ms to 32.00ms (2.50ms unit) 30 26
3.00ms 3.00ms to 32.00ms (3.00ms unit) 30 30
3.50ms 3.50ms to 32.00ms (3.50ms unit) 30 30
4.00ms 4.00ms to 32.00ms (4.00ms unit) 30 30
Byte 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Command 03H 01H - NO. SIZE - WDT
Response 01H 01H ALARM STATUS NO. SIZE PARAMETER RWDT
Note
