Brake cancel request (22H)[BRK_OFF]
To stop servo amplifier with the stop mode specified by HOLD_MOD.
Available phase : Phase 2 and Phase 3
Type of command : non-sync type
Reading cycle : < Communication period
Sub command : Can't use
After receiving command of BRK_OFF, the BRAKE signal is OFF within 2ms.
The command of BRK_ OFF enables only after asigning signal of "electromagnetic brake timing (BRAKE)"
through "output1 asignment (IO_52)", "output2 asignment (IO_53)" and "output3 asignment (IO_54)"
Although BRK_ON or BRK_OFF received in Servo ON cannot be reflected in operation, the reception of
BRAKE signals is enabled.As a result, unexpected operations may occur when the SV_OFF command is
received. So be sure always to keep BRK_ON or BRK_OFF command under control.
■Relevant parameters
Common servo control (3FH)[SVCTRL]
To execute common control of servo motor.
Available phase : Phase 2 and Phase 3
Type of command : non-sync type
Sub command : Available
Compatible command of MECHATROLINK-IIcan perform generic control of servo motor.
If the following warning appears, command will be ignored.
• Receiving SVCTRL command when servo is closed.
• Receiving POSING or FEED command in Phase 1 of the motion.
• Receiving INTERPOLATE command in Phase 3 of motion.
Byte 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Command 03H 22H - SEL_MON1/2 -WDT
Response 01H 22H
ALARM STATUS MONITOR1 MONITOR2 SEL_MON1/2 IO_MON RWDT
Note
Important
Parameter Category Name Set value/setting unit Default
Enable
timing
IO_52
Extend
*Output1 assignment
0 : None
1 : RDY
2 : INPOS/VCMP
3 : BRAKE
4 : TLM/VLM
5 : WARN
6 : ZSP
7 : NEAR
3
When power is
ON again
IO_53 *Output 2 assignment 1
IO_54 *Output 3 assignment 5
Byte 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Command 03H 3FH SUBCTRL OPTION TPOS TSPD/VFF SEL_MON1/2 SQ_CMD WDT
Response 01H 3FH ALARM
STATUS MONITOR1 MONITOR2 SEL_MON1/2 IO_MON RWDT
Byte 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Command Sub command field Can't use
Response Sub command field Can't use
Note
